0.001Lux CVBS Camera Modules: Enabling Night Vision for Next-Gen Drones

As drone technology continues to advance, the demand for reliable night vision capabilities is rapidly growing across industries such as agriculture, security, inspection, and public safety. However, integrating high-performance vision modules into drones poses unique challenges: size, weight, power consumption, and image quality in extremely low-light conditions are all critical factors.

At Shenzhen Novel Electronics, our 0.001Lux CVBS micro camera modules are engineered specifically to meet these needs, enabling next-generation drones to fly safely and capture clear images even in near-total darkness.

The Challenge of Night Vision in Drones

Operating drones during night or low-light conditions is essential for many applications:

• Agricultural monitoring: detecting crop health, pests, or irrigation issues after sunset.
• Security patrols: surveillance of large outdoor facilities or borders at night.
• Search and rescue: locating lost persons in dark or wooded areas.
• Inspection: visual checks of infrastructure like power lines or pipelines in low-light.

Traditional digital cameras often struggle with noise and poor image clarity when illumination drops below a few lux. Thermal imaging cameras, while effective, are costly and bulky.

Hence, a compact, low-light analog camera with stable video output is an attractive option for lightweight drones that need cost-effective night vision.

What is CVBS and Why Choose It?

CVBS (Composite Video Baseband Signal) is an analog video signal format that outputs standard-definition video, compatible with many legacy and embedded video systems.

Key benefits for drone applications include:

• Low latency video output: essential for real-time flight control and navigation.
• Simple wiring and compatibility: can be connected to existing video transmitters and displays without complex processing.
• Low power consumption: extends drone flight time compared to more power-hungry digital systems.
• Compact module size: easier integration in space-constrained drone designs.

0.001Lux Sensitivity: Seeing in Near Darkness

Our CVBS micro camera modules deliver outstanding 0.001Lux sensitivity, meaning they can capture usable images under extremely low ambient light—almost starlight conditions.

This sensitivity is achieved through:

• High-quality CMOS sensors with enhanced infrared response.
• Low-noise signal processing circuitry.
• Optional IR cut filters or IR LEDs for supplemental illumination.

This capability allows drones to perform night missions without relying on bulky infrared lighting, which adds weight and power draw.

Technical Specifications at a Glance

Specification	Details
Resolution	720×480 (NTSC) / 720×576 (PAL)
Minimum Illumination	0.001 Lux (with IR)
Lens Size	21×21mm module size
Field of View (FOV)	90° wide-angle lens standard
Signal Output	Analog CVBS composite video
Operating Voltage	5V DC
Operating Temperature	-20°C to +60°C
Weight	Approx. 15 grams

Real-World Applications

1. Agricultural Drone Night Surveillance

Farmers use drones equipped with our CVBS cameras to monitor crop conditions after dusk, spotting irrigation problems and pest infestations early to protect yields.

2. Security and Border Patrol

Security firms deploy drones with these cameras to provide 24/7 surveillance, enabling real-time monitoring without the need for expensive thermal imaging gear.

3. Search & Rescue Missions

First responders rely on drones fitted with ultra-sensitive CVBS modules to find missing persons in low-light scenarios quickly and accurately.

4. Infrastructure Inspection

Utility companies conduct nighttime inspections of power lines and pipelines using drones with these cameras, reducing downtime and increasing safety.

Why Shenzhen Novel Electronics?

We specialize in producing micro camera modules optimized for UAV and drone applications, offering:

• Small form factor and lightweight design that fits drone payload constraints.
• Competitive pricing suitable for large-scale OEM production.
• Customization support for lens options, wiring lengths, and voltage requirements.
• Fast sample and delivery services to accelerate your development cycle.
• Strict quality control and certifications (CE, RoHS, FCC) for global market compliance.

Integration Tips for Drone Developers

• Power Supply: Ensure stable 5V DC with appropriate filtering to minimize video noise.
• Video Transmission: CVBS output can connect directly to analog video transmitters commonly used in FPV drones.
• Mounting: The compact 21×21mm size facilitates mounting on drone frames or gimbals with minimal vibration impact.
• Environmental Protection: Use IP67-rated housing options for operations in harsh weather conditions.

Conclusion

The 0.001Lux CVBS micro camera module from Shenzhen Novel Electronics offers an ideal blend of ultra-low light performance, compact size, and analog simplicity tailored for drone manufacturers and integrators.

If you aim to expand your drone’s operational envelope into night and low-visibility conditions, our CVBS camera modules provide a cost-effective, reliable vision solution.

Call to Action

Ready to empower your drones with cutting-edge night vision?
Contact us now for samples, detailed specs, and custom integration support.
