A project-oriented visible + thermal camera platform for harsh mobile equipment, designed for OEM/SI customers needing sensor, thermal core, housing, interface, and NRE customization
Goobuy custom dual-spectrum camera platform for harsh mobile equipment combines a visible-light camera and a thermal imaging channel in one configurable system for vehicles and mobile platforms that operate in darkness, dust, fog, rain, snow, mud, vibration and low-visibility industrial sites. Goobuy dual-spectrum platform supports STARVIS visible camera options, 256×192 / 384×288 / 640×512 thermal configurations, custom housing, sealed cable, waterproof connector, AHD / CVBS / USB / Ethernet output evaluation and project-based NRE development for mining vehicles, oilfield service vehicles, remote inspection platforms, industrial patrol vehicles and heavy-duty mobile equipment. It is designed for civil industrial integration projects, not low-cost fleet cameras or weaponized applications.
Goobuy custom dual spectrum camera platform combines a visible-light camera and a thermal imaging module into a configurable vision solution for mining vehicles, oilfield vehicles, gas-field service vehicles, remote inspection platforms, and harsh-environment mobile equipment.
This platform is not positioned as a low-cost truck fleet camera. It is designed for OEMs, system integrators, mining equipment suppliers, oilfield vehicle integrators, and industrial mobile platform projects that already have a host vehicle, display, DVR, embedded controller, AI box, or industrial computer.
Customers can start from an existing dual-spectrum platform configuration for fast sample validation, then move to project-specific customization or NRE development when the optical, mechanical, electrical, environmental, or interface requirements are confirmed.
For higher-level projects, the visible channel can be evaluated with Sony STARVIS sensors such as IMX678 or IMX585, while the thermal channel can be upgraded from 256×192 to 384×288 or 640×512 depending on observation distance, field of view, budget, housing size, and host system architecture.
This visible + thermal camera platform is designed for mobile machines that must operate in low-visibility environments where ordinary visible cameras are not enough.
Typical environments include:
In these applications, the challenge is not only night vision. The real engineering challenge is the combination of darkness, dust, fog, snow, vibration, mud, temperature change, limited installation space, and compatibility with existing vehicle video systems.
| Good Fit For | Not Ideal For |
|---|---|
| Mining vehicle OEMs and integrators | Buyers only looking for the cheapest truck camera |
| Oilfield and gas-field vehicle projects | Consumer car accessory buyers |
| Heavy-duty mobile equipment suppliers | Customers only needing a standard rear-view camera |
| Projects needing visible + thermal imaging | Simple daylight monitoring projects |
| Teams needing custom housing, cable, connector, lens, or output | Buyers who only compare catalog prices |
| Projects with sample timeline, pilot quantity, and NRE possibility | Hobby, DIY, or student projects |
| Harsh-environment mobile platforms | General fleet buyers without customization needs |
If your project already has a vehicle platform, monitor, DVR, embedded controller, or industrial host system, this platform may help you reduce development time compared with building a dual-spectrum camera system from zero.
| Customer Problem | Why Dual-Spectrum May Fit | What Must Be Validated |
|---|---|---|
| Operators lose visibility in dust, darkness, fog, snow or rain | Visible camera provides scene context while thermal channel adds heat-based awareness | FOV, lens, display mode, mounting height and host system |
| Thermal-only image lacks road or equipment detail | Visible channel helps show road edges, terrain, vehicle outline and obstacle context | Visible sensor, low-light performance and lighting conditions |
| Standard vehicle camera is not enough for mining or oilfield sites | Rugged housing, sealed cable, connector and mounting can be discussed by project | Vibration, mud, dust, water, temperature and maintenance access |
| Existing vehicle already uses AHD DVR or MDVR | AHD / CVBS / USB / Ethernet output can be evaluated instead of replacing the full system | Video input type, connector, cable path and display architecture |
| Low-cost thermal resolution is not enough | 384×288 or 640×512 thermal options can be evaluated | Target size, observation distance, FOV and budget |
| Installation space is limited | Housing, bracket, cable outlet and lens direction can be adapted by project | Vehicle drawings, mounting location and mechanical constraints |
| Project needs fast prototype first | Start from an existing dual-spectrum platform before NRE customization | Sample timeline, pilot quantity and customization scope |
| Buyer only wants a cheap truck camera | Not the right product direction | Standard fleet camera may be more suitable |
What Real Problems This Platform Solves for Special Vehicles
Special vehicles used in mining, oilfield, gas-field, Arctic, and heavy industrial environments do not fail because of one single imaging problem. In real projects, the difficulty usually comes from the combination of poor visibility, harsh mechanical conditions, existing vehicle video architecture, and limited installation space.
Goobuy dual spectrum vision platform is designed to help OEMs and system integrators solve these practical project-level problems.
| Real Project Pain Point | How the Dual Spectrum Platform Helps |
|---|---|
| Operators lose visual awareness in dust, darkness, fog, snow, smoke, or rain | The visible channel provides scene detail and road context, while the thermal channel adds heat-based awareness when visible imaging becomes unreliable. |
| Thermal imaging alone does not show enough road structure or equipment detail | The visible camera helps show terrain, vehicle outline, road edges, machine position, obstacles, and environmental context. |
| Standard visible cameras cannot provide enough confidence for night or low-light operation | The visible channel can be upgraded to Sony STARVIS options such as IMX678 or IMX585 for projects requiring stronger low-light scene detail. |
| A low-resolution thermal camera may not be enough for longer observation distance or higher-value projects | The thermal channel can start from 256×192 and be evaluated with 384×288 or 640×512 options depending on distance, FOV, target size, display method, and budget. |
| The customer already has an AHD monitor, DVR, MDVR, industrial PC, or AI box | The platform can be discussed around AHD, CVBS, USB, or Ethernet output instead of forcing the customer to replace the whole vehicle video system. |
| The camera must fit a special mounting position on a mining truck, oilfield vehicle, inspection vehicle, or mobile machine | Housing size, bracket, cable outlet, connector, lens direction, and mounting method can be evaluated based on the actual vehicle structure. |
| Cable, connector, sealing, vibration, and low-temperature requirements are different from ordinary vehicles | Goobuy can evaluate sealed connectors, custom cable length, waterproof design, rugged housing, and project-based environmental requirements. |
| The project needs a fast prototype but may later require deeper customization | Customers can start from an existing platform configuration for feasibility validation, then move to platform-based customization or NRE development after requirements are confirmed. |
This platform is most valuable when the customer already has a real vehicle project, a host system, a sample timeline, and a clear reason why a standard vehicle camera cannot meet the application requirement.
For Goobuy, the goal is not to replace every truck camera. The goal is to help engineering teams build a project-specific visible + thermal vision solution faster, with configurable sensor, thermal core, lens, housing, cable, connector, video output, and NRE development options.
This dual-spectrum vehicle camera platform combines visible imaging and thermal imaging to support mining vehicles, oilfield service vehicles and heavy-duty mobile equipment in rain, fog, dust, glare, darkness and other low-visibility conditions
Goobuy can support different configuration levels depending on the project stage, budget, and system architecture.
| Module | Standard Platform | Enhanced / Custom Options |
| Visible Camera | 1080P visible camera | Sony STARVIS IMX385 / IMX678 / IMX585 options |
| Thermal Core | 256×192 thermal imaging | 384×288 / 640×512 thermal options |
| Lens / FOV | Standard vehicle FOV | Wide-angle / standard / telephoto / custom FOV |
| Video Output | AHD option | CVBS / USB / Ethernet project evaluation |
| Housing | Rugged vehicle-style housing | Compact, embedded, mining vehicle, or oilfield vehicle custom housing |
| Cable | Standard cable | Custom length, shielding, waterproof cable, sealed connector |
| Connector | Standard connector | Aviation connector / waterproof connector / project-specific connector |
| Mounting | Standard bracket | Front / side / roof / embedded mounting adaptation |
| Integration | Direct monitor or DVR | Industrial PC, embedded controller, AI box, or software-level access |
| Development Path | Platform configuration | Platform-based customization or NRE development |
The platform can be adapted according to the customer’s actual vehicle structure, host interface, installation location, image quality requirement, and pilot production plan.
The visible channel can be configured according to the required image quality, low-light performance, resolution, lens size, and host interface.
For standard projects, a 1080P visible camera can provide basic scene detail and daytime visibility.
For higher-level projects, Goobuy can evaluate Sony STARVIS-based visible camera options such as IMX385, IMX678, or IMX585. These options may be suitable when the project requires stronger low-light visible imaging, better scene detail, improved night performance, or higher image quality than a generic vehicle camera.
Typical visible camera upgrade considerations include:
The thermal channel can start from a cost-effective 256×192 configuration for initial validation or cost-sensitive applications.
For projects requiring more thermal detail, longer observation distance, or higher-level imaging performance, 384×288 or 640×512 thermal options can be discussed.
Thermal resolution selection should not be decided by resolution alone. The final performance depends on:
Goobuy can help customers evaluate whether the existing platform is sufficient or whether a higher-resolution thermal configuration should be considered through project-based customization.
Many mining and oilfield vehicle projects already have an existing video architecture. The customer may already use an AHD monitor, DVR, MDVR, embedded controller, industrial PC, or AI processing box.
For this reason, Goobuy does not treat the camera as an isolated product. The platform can be discussed based on how the customer plans to connect, display, record, or process the image.
Possible output directions include:
The final output architecture depends on whether the customer needs direct display, recording, dual-channel output, software processing, image fusion, or integration with an existing industrial system.
Mining vehicles, oilfield vehicles, and heavy-duty mobile equipment often have very different installation conditions from ordinary trucks.
A standard camera housing may not fit the required location. Cable outlet direction, connector type, lens angle, bracket style, sealing method, and mounting space may all need adjustment.
Goobuy can evaluate customization for:
This is one of the main reasons to use a configurable platform instead of purchasing a standard vehicle camera
| No. | Item | Specification |
|---|---|---|
| 1 | Product Type | Commercial Vehicle Dual-Spectrum Thermal Imaging Module |
| 2 | Installation Scenario | Front-top mounting above the driver cabin |
| 3 | Housing Material | High-density aluminum alloy |
| 4 | Module Weight | 300g N.W. / 350g G.W. |
| 5 | Operating Voltage | DC12V ±10% |
| 6 | Operating Current | ≤300mA @12V |
| 7 | Rated Power | ≤3.5W @12V |
| 8 | Tail Cable Connector | 4-pin waterproof aviation connector |
| 9 | Tail Cable Length | L = 1m |
| 10 | Thermal Imaging Mode | White-hot mode |
| 11 | Thermal Pixel Pitch | 12μm WLP |
| 12 | Thermal Spectral Range | 8–14μm |
| 13 | Thermal Detection Lens | 7.0mm fixed-focus lens, 5m to infinity |
| 14 | Thermal Field of View | Horizontal 29° × Vertical 20° |
| 15 | Thermal Detection Distance | Detection / recognition distance: 100m |
The specifications above describe the basic dual-spectrum vehicle camera platform. This version can be used as a starting point for sample validation, vehicle mounting evaluation, AHD/DVR compatibility testing, and harsh-environment application assessment.
For higher-level mining vehicle, oilfield vehicle, Arctic industrial vehicle, remote inspection vehicle, and heavy-duty mobile equipment projects, Goobuy can further customize or redesign the platform according to the customer’s real application requirements.
Available upgrade and customization directions may include:
| Custom Area | Possible Upgrade Options |
|---|---|
| Visible Camera | Standard visible camera / Sony STARVIS IMX385 / IMX678 / IMX585 |
| Thermal Resolution | 256×192 / 384×288 / 640×512 project evaluation |
| Thermal Lens | Different focal length and FOV options based on observation distance |
| Video Output | AHD / CVBS / USB / Ethernet evaluation |
| Housing | Compact housing, rugged housing, custom mounting structure |
| Cable | Custom cable length, shielding, waterproof cable, special routing |
| Connector | 4-pin aviation connector, waterproof connector, project-specific connector |
| Mounting | Roof, front, side, embedded, or bracket-based installation |
| Environmental Design | Waterproofing, vibration, low-temperature, dust and mud exposure review |
| Development Path | Existing platform configuration / platform-based customization / NRE development |
This basic model is only the starting configuration of Goobuy’s dual-spectrum vehicle camera platform. For projects requiring stronger low-light visible imaging, longer thermal observation distance, higher thermal detail, special mechanical installation, or integration with an existing vehicle video system, Goobuy can evaluate upgraded configurations such as Sony STARVIS IMX678 / IMX585 visible cameras, 384×288 or 640×512 thermal imaging options, custom lens/FOV, AHD/CVBS/USB/Ethernet output, custom housing, cable, connector, and project-based NRE development.
If your mining vehicle, oilfield service vehicle, remote inspection platform, Arctic industrial vehicle, or heavy-duty mobile equipment already has a host system, monitor, DVR/MDVR, industrial PC, or AI box, please send us your application environment, required output, installation space, expected observation distance, pilot quantity, and customization scope. Goobuy can help evaluate whether the existing platform is sufficient or whether a higher-level custom version should be developed.
Open-pit mining trucks, mining transport vehicles, and heavy-duty mobile machines often operate in dust, darkness, fog, rain, mud, and vibration. A dual-spectrum camera can combine visible scene detail with thermal awareness to support low-visibility operation.
Typical requirements may include rugged housing, sealed cable, AHD/DVR compatibility, custom mounting, and thermal resolution selection based on the expected observation distance.
Open-pit mining trucks, mining transport vehicles, and heavy-duty mobile machines often operate in dust, darkness, fog, rain, mud, and vibration. A dual-spectrum camera can combine visible scene detail with thermal awareness to support low-visibility operation.
Typical requirements may include rugged housing, sealed cable, AHD/DVR compatibility, custom mounting, and thermal resolution selection based on the expected observation distance.
Oilfield and gas-field vehicles may operate at night, in snow, mud, rain, fog, and remote industrial locations. Standard visible cameras may not provide enough awareness in poor visibility.
A visible + thermal platform can be configured for service vehicles, inspection vehicles, maintenance vehicles, and industrial patrol vehicles used around oil and gas infrastructure.
Typical customization may include waterproof connector, low-temperature requirement evaluation, custom cable length, STARVIS visible imaging, and thermal resolution upgrade.
Cold-region and Arctic industrial vehicles may face snow, fog, low light, long winter nights, low temperature, and difficult maintenance conditions.
For these projects, Goobuy can evaluate low-temperature requirements based on the customer’s operating environment, installation location, housing requirement, cable material, sealing method, and validation standard.
Energy facilities, mining sites, pipelines, ports, and large industrial areas may use mobile inspection vehicles or patrol platforms for remote observation.
A configurable dual-spectrum platform can help system integrators adapt visible and thermal imaging to an existing vehicle, DVR, embedded controller, or industrial host system.
Construction equipment, port machinery, yard vehicles, industrial transport platforms, and rugged mobile systems may require more than a standard rear-view camera.
For these projects, the main value is not only image output. The value is the ability to configure the sensor, lens, housing, connector, output, and integration path according to the actual machine.
This platform can be evaluated for civil industrial mobile equipment where standard visible cameras cannot provide enough confidence in low visibility.
Typical project directions include:
The platform is most valuable when the customer needs a configurable camera head, not a catalog vehicle camera. Housing, cable, connector, output, visible sensor, thermal resolution, lens FOV and mounting direction should be evaluated with the actual vehicle structure.
To evaluate whether the existing platform can be configured quickly or whether project-specific NRE development is required, please send us your project information.
Useful information includes:
The more clearly you describe the project background, the faster Goobuy can evaluate the technical direction, customization scope, development risk, sample lead time, and estimated cost.
If your project already has a vehicle platform, host system, display/DVR architecture, sample timeline, or first-batch quantity, send us your requirements.
Goobuy can evaluate whether the existing dual-spectrum platform can be configured quickly or whether a project-specific NRE development path is required.
Please include your vehicle type, working environment, host system, required output, visible camera expectation, thermal resolution requirement, installation space, timeline, pilot quantity, and customization scope.
Discuss Custom Configuration
Request NRE Feasibility Review
Send Project Requirements
Professional FAQ
1. We already have an AHD monitor and DVR on our mining vehicle. Can your visible + thermal camera platform be adapted without replacing our whole video system?
Yes. Many mining and oilfield vehicle projects already have an existing monitor, DVR, MDVR, or vehicle display architecture. Goobuy can evaluate AHD output for direct connection to your current video system, and CVBS, USB, or Ethernet output can also be discussed depending on whether you need simple display, recording, embedded processing, or software-level image access. The key is to confirm your current video input format, connector, cable routing, display mode, and whether you need one combined output or separate visible and thermal channels.
2. Our vehicles operate in dust, fog, darkness, mud, vibration, and low temperature. Is this only a normal vehicle camera with a thermal sensor added, or can it be engineered for harsh working conditions?
This platform is not positioned as a standard truck fleet camera. It is intended for harsh-environment mobile equipment where standard visible cameras often fail because of dust, low light, fog, snow, mud, vibration, and limited installation space. Goobuy can evaluate rugged housing, sealed cable, waterproof connector, mounting direction, lens protection, cable outlet design, and project-based low-temperature requirements. For mining, oilfield, gas-field, or Arctic vehicle projects, we recommend sharing the actual working temperature, vibration exposure, installation position, sealing requirement, and maintenance conditions before quotation.
3. We are not sure whether 256×192 thermal resolution is enough. When should we consider 384×288 or 640×512 thermal imaging?
256×192 thermal imaging can be suitable for cost-sensitive projects, short-to-medium observation distance, or early feasibility validation. If your project requires more thermal detail, longer observation distance, wider scene coverage, or better operator confidence in harsh visibility conditions, 384×288 or 640×512 should be evaluated. The correct choice depends not only on resolution, but also on lens focal length, FOV, target size, vehicle speed, display size, operating environment, and budget. For serious projects, Goobuy recommends discussing the expected observation distance, target type, FOV, and installation position before selecting the thermal configuration.
4. We need better visible imaging than a generic 1080P vehicle camera. Can the visible channel use Sony STARVIS IMX678 or IMX585?
Yes. For projects where the visible channel must provide stronger low-light detail, better night scene context, higher resolution, or improved image quality, Goobuy can evaluate Sony STARVIS visible camera options such as IMX678 or IMX585. This is useful when thermal imaging alone is not enough and the operator still needs road structure, terrain detail, object outline, equipment position, or visual context. The final sensor choice depends on required resolution, lens size, interface, housing space, low-light level, host system, and project budget.
5. Our installation space is limited and a standard vehicle camera housing will not fit. Can you customize the mechanical structure?
Yes. Mechanical customization is one of the main reasons to use this platform instead of a standard catalog camera. Goobuy can evaluate custom housing size, bracket design, cable outlet direction, connector type, lens angle, visible/thermal window position, mounting direction, and waterproof sealing method. For faster evaluation, please provide the available installation space, mounting surface, preferred viewing direction, cable route, connector requirement, and whether the camera must be front-mounted, side-mounted, roof-mounted, or embedded into an existing vehicle structure.
6. We are a system integrator, not an end user. Can you support a prototype-to-pilot development path instead of only selling samples?
Yes. This platform is suitable for system integrators and OEM customers who need to move from concept validation to prototype, pilot batch, and small-to-mid volume production. A typical path is: first, evaluate an existing dual-spectrum platform; second, adjust lens, output, cable, connector, and housing for prototype testing; third, start project-based NRE development if a new sensor combination, 640×512 thermal option, custom structure, special interface, or firmware-level adaptation is required. Goobuy prefers projects with a clear host platform, sample timeline, pilot quantity, and NRE budget expectation.
7. Can this platform output both visible and thermal images separately, or support overlay / split-screen display?
This depends on the selected hardware architecture, output interface, and project requirements. Some projects only need a direct display output, while others may need separate visible and thermal channels for recording, processing, or host-side fusion. Overlay, split-screen, or separate-channel output can be evaluated during the project feasibility stage. Before confirming the design, please clarify whether your system needs operator display, DVR recording, AI box input, software access, or dual-channel processing.
8. What information should we send so you can judge whether this can be configured quickly or needs NRE development?
Please send the project background instead of only asking for price. The most useful information includes vehicle type, application environment, host system, current video input, required output, visible image requirement, thermal resolution expectation, target observation distance, FOV, installation space, mounting direction, cable and connector requirement, waterproof or low-temperature requirement, prototype timeline, pilot batch quantity, estimated annual volume, and whether NRE customization is acceptable. With this information, Goobuy can evaluate whether the existing platform can be configured quickly or whether a project-specific NRE development path is more realistic.
