7'' 4CH Semi Truck Camera System

  • 7'' 4CH Semi Truck Camera System
  • 7'' 4CH Semi Truck Camera System
  • 7'' 4CH Semi Truck Camera System
7'' 4CH Semi Truck Camera System
  • model: T-301
Product description

Product Details

7 inch 4ch Commercial Vehicle Camera System For Truck and Bus

7" Quad Monitor Screen Combo DVR Video Recorder +4 Front Side Rear View Dash Camera System with DVR For Semi Truck BUS

4 Channel Vehicle DVR System

Product Feature of Semi Truck Camera Systems with DVR recording

1. CPU: AllWinner

2. Automatically loop-cycle recording

3.7inch HD High light screen display, 800x480

4.3.Camera lens : 4 CHS AHD 720P, 120 degree, @ 25fps

6. Maximum support 128GB card, could record about 34Hrs

7. Support Parking Reverse

8. Support Automatic switch between left and right turn signals

9. Support adjust the 4 cameras mirrored

10. Support 4 split screens and 10 display modes

11.Powered by connecting with Car insurance box's ACC and BAT +

12, Connecting 5M(16ft) & 10M(33ft) 4Pin high quality anti interference extension cable for camera

7inch DVR Monitor

This 4 Channels Semi Truck Camera System can install front forwarding view Semi Truck Camera, Rearview Cameras, Left Side Camera, Right Side Camera total 4 Cameras plus one 7inch combo DVR that support 4 channels camera video at same time on various kinds of commercial truck and bus ( it can record 4 cameras video during driving)  to build up complete Vehicle DVR System for truck/bus 360 Safety Security

Product Specification of 4 Camera DVR System For Bus

Item name

Technical data

product name

Panoramic 720P 4 Channel Commercial Vehicle Camera System


Allwinner Chipset


4pcs AHD 720P camera, full starlight color, Starlight night vision

Video pixel

1.0megapixels HD720P

Monitor Display screen size

7 inch digital monitor screen

Resolution of Monitor Display


AHD Monitor


A+ class 4 glass high resolution wide Angle lens


Chinese (Jane), English

Video Format

TS Streaming Media

video file format


trigger display

Automatically switches to the corresponding camera view

Video resolution


Color Effect


Recording in an uninterrupted loop

Seamless loop recording, no loss of seconds

Switch on and off with the car

Support car ignition boot recording flameout shutdown

Year, month, day



DDR3 512M

lens Aperture


night vision function


memory card

C10 TF card(Support high speed32GB-128GB)

RVC ( reversing control)

Support Reversing trigger



Voice Control


Built-in audio


Current frequency



12-35V wide voltage

Material of Camera Case

Metal, Colorful Case custom-made/OEM

MP5 play function

Optional add or customize


Three 5m video cables, one 15m video cable with trigger and shield

Product Application

Semi-Truck, Heavy duty, trailer truck, farm machinery, school bus, SUV

Semi Truck Camera System Kit

Package of 4 Channels Vehicle DVR Included:

1x 7''DVR Monitor

1x Monitor Dashboard Base

2x AHD Front/Backup Camera

2x AHD Side View Camera

1x 15M 4Pin Extension Cable

3x 5M 4Pin Extension Cable

1x Remote Control

AHD Truck Cameras

Product Application of 4 Channels Vehicle DVR Commercial Vehicle Camera Systems

1, Scania, DAF, MAN, Benz, TATRA and Volvo Commercial truck and heavy duty vehicle 360 degree monitoring

2, For Passenger Bus, School Bus, City Bus, Travel bus, Coach bus, Sightseeing Bus, Airport shuttle, Autobus, 360 School bus surveillance system

3, bmw, suvs, private car automobile Airport Vehicles, Airport Baggage Van, Delivery van Vehicle etc

4,Automotive around surround view camera monitoring system for Semi truck and trailer

5.portable 4 Channel Vehicle DVR System can work for Semi Truck, Commercial Truck, Tanker truck, Transport Logistics vehicles, Trailer, VAN, Articulated dump truck, Rigid truck, Truck-trailer combination, Longer Heavier Vehicles, Bulk truck, Container- / hooklift truck, Tipper truck,
